SW956E
Electric Mini Excavator
Bucket Capacity
3.5 m³
Rated Payload
5.8 T
Operating Weight
19 T
Features
Structure Reliability
- Braking System: Dual-pipe complete hydraulic service braking system, sensitive response, and low failure rate.
- Axles： a heavy-duty drive axle with strong bearing capacity and low failure rate.
-
Frame: High-strength frame; double tapered roller bearings at the hinges.
Electrical System Safety
- Battery Safety: Reasonable layout; in line with the safety requirements of the standard GB38031; when exceptional circumstances such as collision and extrusion occur, the battery components will not have the danger of shell rupture, fire, or explosion, ensuring the safety of the driver's life.
-
Online Monitoring: Big data multiple early warnings, fault prediction; client app pushes real-time information to ensure people's and equipment's safety.
Higher Efficiency
- High-power permanent magnet synchronous motor, fast dynamic response.
- Two-speed gearbox, higher transmission efficiency.
-
Integrated FNR function pilot joystick, smooth and fast shifting.
Comfort and Maneuverability
- Using silicone oil mounting technology, the vibration frequency of the cab is reduced to 1Hz.
- The vibration of the electric drivetrain system is reduced by 30% compared with the fuel loader.
- The seat design adopted an ergonomic, more comfortable, and convenient design.
-
High-power dual-purpose air conditioner reduces heating and cooling time by 30%.
Specs
3.5 m³
Bucket Capacity
19 T
Operating Weight
225 kW
Engine Power
12.040 T
Straight Turn Tipping Load
5.8 T
Rated Payload
11.632 T
Full Turn Tipping Load
